High Head Pressure Anti- Abrasive 3/2 D-Hh Slurry Pumps

Product Description

3/2 D-Hh High Head Pressure Anti- Abrasive Slurry Pumps

Name: YL-HH High Head Slurry Pump
Pump Type:Centrifugal Slurry Pump
Drvie Type: ZVz/CRz/CV/DC
Power: motor/diesel
Discharge Size: 1to 6 inch
Capacity: 16.2-1008m³/h
Head: 25-118m
Wet end parts : High Chrome Alloy
Pump Model : 1.5/1C-HH 3/2D-HH 3/2DD-HH 4/3E-HH 4/3EE-HH 6/4F-HH 6/4FF-HH 6/4x- HH 6S-H 8/6S-H 8/6X-H 6S-HP 8/6S-HP 8/6X-HP

SLURRY PUMP PERFORMANCE PARAMETERS

Type	Allowable Mating Max. Power(Kw)	Clear Water Performance					Impeller
Type	Allowable Mating Max. Power(Kw)	Capacity/Q m³/hr	Head/m	Speed/rpm	Max Efficiency/%	NPSH/m	Nos of Vane	Impeller Diameter/mm
1.5X1C-YL-HH	30	16.2--34.2	25-92	1400--2200	20	2--5.5	5	330
3X2D-YL-HH	60	68.4--136.8	25-87	850--1400	47	3-7.5	5	457
4X3E-YL-HH	120	126-252	12-97	600-1400	50	2-5	5	508
6X4F-YL-HH	560	324-720	30-118	600-1000	64	3-8	5	711
8X6S-YL-HH	560	468-1008	20-94	500--1000	65	4-12	5	711

Feature:

High heads per stage at high pressures. commonly used for long distance transport lines, the lines can often satisfy application duties with a single pump where others require multiple pumps.the range is capable of handling medium size particles and pumping at heads in excess of 90 meters per stage.

Materials & Wear Resistance
- **High-Chrome Alloy**
- **Rubber-Lined**
- **Ceramic Lined**
- **Polyurethane**
- **Wear-Resistant Coating**
- **Abrasion Resistance**
- **Corrosion Resistance**

Pump Types
- **Slurry Pump**
- **Centrifugal Slurry Pump**
- **Horizontal Slurry Pump**
- **Vertical Slurry Pump**
- **Submerged Slurry Pump**
- **Bubble Slurry Pump**
- **Dredge Pump**
- **Froth Pump**
- **Heavy-Duty Slurry Pump**
- **Sand Pump**

Typical Applications---
*Mining Industry** -
- **Coal Processing**
- **Mineral Processing**
- **Dredging**
- **Power Plant**
- **Chemical Industry**
- **Wastewater Treatment**

Common Issues & Maintenance
- **Clogging**
- **Cavitation**
- **Seal Failure**
- **Bearing Overheating**
- **Wear Inspection**
- **Alignment Check**
- **Lubrication**
---

Keywords

Ductile iron

HH Slurry Pump

Solid Slurry Pump Hh High Head Slurry Pump

Factory description

Hebei Yuezhong Longhui Import and Export Trading Co., Ltd. is a trade enterprise specializing in the export of slurry pump products.Leading products include ZJ, AH, HH, AM, and YZ series slurry pumps.Depending on different user requirements and medium content, various high-strength corrosion-resistant, wear-resistant, and high-temperature resistant materials are selected.Products are widely used in industries such as power, petroleum, metallurgy, chemical, and mining.With technology as the foundation of service and customer demand as the core of service, the company uses professional services to create products that satisfy customers.

Why Choose US

FAQ

Are you a trading company or manufacturer?

we are real integrated set of industry and trade company.

How about your pump price?

We are sure our price is factory price, and insist on high quality for our long-term cooperation.

How does your factory do regarding quality control?

We have a professional quality inspection department that is fully responsible for the quality of the products.

How to do if the pump or parts have operation problems within your warranty?

Tell me details timely, and show me pictures, we will send you the pump solution at once without any hesitation.

High Head Pressure Anti- Abrasive 3/2 D-Hh Slurry Pumps

HH high head slurry pumps widely used for wet crushers, SAG mill discharge, ball mill discharge, rod mill discharge, Ni acid slurry, coarse sand, coarse tailings
