Product Description
3/2 D-Hh High Head Pressure Anti- Abrasive Slurry Pumps
- Name: YL-HH High Head Slurry Pump
- Pump Type:Centrifugal Slurry Pump
- Drvie Type: ZVz/CRz/CV/DC
- Power: motor/diesel
- Discharge Size: 1to 6 inch
- Capacity: 16.2-1008m³/h
- Head: 25-118m
- Wet end parts : High Chrome Alloy
- Pump Model : 1.5/1C-HH 3/2D-HH 3/2DD-HH 4/3E-HH 4/3EE-HH 6/4F-HH 6/4FF-HH 6/4x- HH 6S-H 8/6S-H 8/6X-H 6S-HP 8/6S-HP 8/6X-HP
SLURRY PUMP PERFORMANCE PARAMETERS
|
Type |
Allowable Mating Max. Power(Kw) |
Clear Water Performance |
Impeller |
|||||
|
Capacity/Q m³/hr |
Head/m |
Speed/rpm |
Max Efficiency/% |
NPSH/m |
Nos of Vane |
Impeller Diameter/mm |
||
|
1.5X1C-YL-HH |
30 |
16.2--34.2 |
25-92 |
1400--2200 |
20 |
2--5.5 |
5 |
330 |
|
3X2D-YL-HH |
60 |
68.4--136.8 |
25-87 |
850--1400 |
47 |
3-7.5 |
5 |
457 |
|
4X3E-YL-HH |
120 |
126-252 |
12-97 |
600-1400 |
50 |
2-5 |
5 |
508 |
|
6X4F-YL-HH |
560 |
324-720 |
30-118 |
600-1000 |
64 |
3-8 |
5 |
711 |
|
8X6S-YL-HH |
560 |
468-1008 |
20-94 |
500--1000 |
65 |
4-12 |
5 |
711 |
Product Description
centrifugal slurry pump advantage:
high head
large capacity
high performance
Detailed description of centrifugal slurry pump
1) Cantilevered, horizontal, centrifugal, one stage, single casing gravel (sand) pump
2) High head, large capacity, high efficiency.
3) Good NPSH performance.
Key Components)**
- **Impeller**
- **Casing**
- **Shaft**
- **Shaft Sleeve**
- **Wear Plate**
- **Liner**
- **Seal Assembly**
- **Mechanical Seal**
- **Gland Packing**
- **Bearing Assembly**
- **Suction Pipe**
- **Discharge Pipe**
Keywords
Factory description
Hebei Yuezhong Longhui Import and Export Trading Co., Ltd. is a trade enterprise specializing in the export of slurry pump products.Leading products include ZJ, AH, HH, AM, and YZ series slurry pumps.Depending on different user requirements and medium content, various high-strength corrosion-resistant, wear-resistant, and high-temperature resistant materials are selected.Products are widely used in industries such as power, petroleum, metallurgy, chemical, and mining.With technology as the foundation of service and customer demand as the core of service, the company uses professional services to create products that satisfy customers.
Why Choose US
FAQ
Are you a trading company or manufacturer?
we are real integrated set of industry and trade company.
How about your pump price?
We are sure our price is factory price, and insist on high quality for our long-term cooperation.
How does your factory do regarding quality control?
We have a professional quality inspection department that is fully responsible for the quality of the products.
How to do if the pump or parts have operation problems within your warranty?
Tell me details timely, and show me pictures, we will send you the pump solution at once without any hesitation.
